Hardware Specifications
| Vendor/Brand | Zyxel |
| Model | PM5100-T0 |
| Chipset | MediaTek/EcoNet EN7523OT |
| Flash | 128 MB (Macronix W25N01G) |
| RAM | 256 MB (Winbond W623GU6MB) |
| System | |
| 2.5GBaseT | Yes |
| Optics | SC/APC |
| IP address | 192.168.0.1/24 |
| Web Gui | ✅ |
| SSH | ✅ |
| Telnet | ✅ |
| Serial | ✅ |
| Form Factor | ONT |
List of software versions
- V5.42-ACEQ-0b10 (Cetin)
- V5.42-ACBF.1.1-C0 (Zyxel)
Unlock bootloader and root shell
Full linux shell can be accessed if the current firmware allows it, this ONT has per-device password burned into flash.
Depending on Z-Loader version bootloader access might be protected with supervisors password until EngDebugFlag is enabled.
Default passwords can be obtained with normal ATEN/ATSE unlock process.
sh
# Generate unlock seed
ATSE PM5100-T0
# Generate ATEN key with https://github.com/cjdelisle/ATENv3
ATEN 1,RESULT
# Allow nvram write
ATBT 1
# Write EngDebugFlag to nvram
ATSB
# Dump passwords from nvram
ATCKIf network upgrade isn't disabled by ISP branding zyeng tool can be used to write EngDebugFlag it over the network.
When both methods fail only option is to desolder the SPI flash and locate passwords inside U-Boot ENV.
